Model: FG-H-16

Size: 783*504*995mm (trolley height)

Table: 695*485mm

1. The trolley uses the Taiwan Qimei ABS pellet pure material Injection molding, the configuration transparent soft glass, facilitates the clean up. ABS Material Concave cart effectively prevents the item to glide in the Mesa, the intensity is high, the color is full conforms to the health care use environment;

2. Equipped with intelligent terminal 21.5-inch medical dedicated machine, built-in lithium battery, wireless receiver, charging 4 hours of work 8 hours, interface rich;

3. All aluminum body of aviation, the column uses half arc anti-collision double T design, carrying capacity is big. Stainless steel wire rod connection table, so that the trolley is stable and not deformed, beautiful and durable, side plate, back plate unique honeycomb bionic design, light and solid to achieve a perfect fusion, external painting using the Netherlands Su Nobel Environmental protection powder, surface fine, adhesion, corrosion resistance, wear-resistant ability;

4. The whole trolley adopts ABS aviation aluminum body innovative structure way, more lasting antirust innovation technology, 360 degree anti-collision design, more durable;

5. humanized Universal Screen bracket angle 20 degrees, about 180 degrees;

6. Hidden ABS Deputy worktable design, effectively extend the working space of the table surface, can also do mouse work area;

7. Built-in anti-accidental open locking device mute slide, integrated auto-closed damping module to achieve automatic buffering back function. Selection of 1.2/1.2/1.5mm thickness of the ball frame, bearing superior performance, push and pull smooth without noise, effectively solve the drawer in the process of easy to slip out of the problem;

8. Five ABS material drawer: Two use height 65MM shallow drawer (medicine box Height 50MM, the first layer also can be used as keyboard drawer), two use height 140MM middle drawer and one use height 190MM deep drawer (medicine box height 125MM), meet the need of placing different height first aid supplies. Drawer interior Set free Modular insert, random combination, can be separated by 20, the whole medicine box can be easily taken out;

9. Safe control lock, can lock all drawers at the same time, effective protection of goods safety;

10. The upper side of the body hanging dipping basket, can be placed hand-washing liquid barrels, sharps barrels, with garbage cans below, can easily pick off;

11. General-purpose scanning gun suspension bracket, practical and strong;

12. Equipped with winding, mute medical casters, shore 50 degrees of high elasticity TPR material tires, do not degumming, Non-stick. PA6 material wheel frame, better than 10 times times the steel structure of the same product, no rust, no paint stripping. High-precision deep groove bearings, turning light, turning accurate, to create a congenital mute effect. Double brake caster design more intimate;

13. Trolley Warranty Three years, medical mute caster warranty for five years, medical machine computer warranty one year;

14. According to the needs of medical work, customized multi-functional personalized needs;

15. The whole trolley delivery, without installation, the user as long as the attachment can be suspended;

16. The Logistics transportation uses the whole enclosed wooden box packing, guarantees the user to receive the intact goods in time;
